NVIDIA® Jetson Orin™ NX and Jetson Orin Nano Compact Carrier Board - DSBOARD-ORNXS
DSBOARD-ORNXS is a game-changing innovation that redefines the concept of productivity and connectivity. Powered by the NVIDIA Jetson Orin Nano and Orin NX, this compact and versatile device brings unmatched processing power.
Choose options
COMPACT YET POWERFUL: Unleash the Potential
DSBOARD-ORNXS is a game changing innovation that redefines the concept of productivity and connectivity. Powered by the NVIDIA Jetson Orin Nano and Orin NX, this compact and versatile device brings unmatched processing power. With its seamless WiFi and Bluetooth connectivity, you can effortlessly collaborate and communicate with your team, breaking down barriers and unlocking new levels of efficiency.
Equipped with impressive memory options ranging from 4 GB to 16 GB of lightning-fast LPDDR5, the DSBOARD-ORNXS ensures smooth multitasking and effortless data handling. Its graphics interfaces, including a Mini DisplayPort with a maximum resolution of 3840x2160, deliver stunning visuals that elevate your work to a whole new level. Plus, with multiple extension sockets, including M.2 Key-E and 5V FAN, you have the flexibility to customize and expand your device to suit your specific needs.
High-Performance Compact Carrier Board
The DSBOARD-ORNXS redefines productivity and connectivity in a compact carrier board. Powered by the NVIDIA Jetson Orin Nano and Orin NX, it delivers unmatched processing power for industrial and autonomous applications. This makes it perfect for edge computing tasks requiring high performance in a small form factor.
Seamless Connectivity Options
Stay connected effortlessly with built-in WiFi and Bluetooth capabilities. The DSBOARD-ORNXS features 2x Gigabit Ethernet ports and 2x USB 2.0 interfaces, ensuring fast and reliable data transfer. These connectivity options enable seamless integration with various devices and networks.
Advanced Memory and Storage
Equipped with up to 16 GB of lightning-fast LPDDR5 memory, the DSBOARD-ORNXS ensures smooth multitasking and efficient data handling. The M.2 Key-M SSD slot offers convenient mass storage solutions, enhancing the board's flexibility and performance.
Stunning Visuals
Enjoy stunning visuals with the Mini DisplayPort supporting up to 4K Ultra HD resolution. This high-quality display output makes the DSBOARD-ORNXS ideal for applications requiring detailed graphical outputs, such as industrial automation and robotics.
Versatile Expansion Sockets
Customize and expand your setup with multiple extension sockets, including M.2 Key-E, 5V FAN, SPI, I2S, and UART. These expansion options provide the flexibility to tailor the DSBOARD-ORNXS to specific project needs, ensuring optimal performance and scalability.
Reliable Operation in Harsh Environments
Designed to operate reliably across a wide temperature range (-25°C to +85°C) and input voltage range (9-28 VDC), the DSBOARD-ORNXS is built for harsh industrial environments. Its rugged construction ensures long-lasting durability and stable performance.
NVIDIA® Jetson Orin™ NX and Jetson Orin Nano Compact Carrier Board - DSBOARD-ORNXS Use Cases
Drones/UAVs
FORECR's rugged industrial-grade computing solutions, integrated with NVIDIA Jetson modules, empower drones and UAVs with advanced capabilities such as autonomous navigation, real-time data processing, and object detection, enabling applications in surveillance, mapping, and delivery services.
Industrial Automation
FORECR's industrial-grade computing solutions, featuring NVIDIA Jetson modules, optimize industrial automation processes by enabling real-time monitoring, control, and data analysis for enhanced productivity and efficiency in manufacturing facilities.
Autonomous Systems
Enable seamless integration into autonomous systems for various applications such as self-driving vehicles, drones, and robotic platforms, facilitating real-time decision-making and navigation in dynamic environments.
NVIDIA® Jetson Orin™ NX and Jetson Orin Nano Compact Carrier Board - DSBOARD-ORNXS Technical Specifications
| Supported Modules |
NVIDIA Jetson Orin Nano 4GB / 8GB NVIDIA Jetson Orin NX 8GB / 16GB |
| Memory |
4 GB 64-bit LPDDR5 / 8 GB 128 bit LPDDR5 8 GB 256-bit LPDDR5 / 16 GB 128 bit LPDDR5 |
| Graphics Interfaces |
1x Mini DisplayPort (max resolution 3840x2160) |
| Interfaces |
2x Gigabit Ethernet 2x USB 2.0 1x CAN Bus 2X CSI 4-LANE 1x 3.0 Type-C (Recovery) 1x UART (Debug - 3.3V) 1x RTC |
| Wireless Communication |
WiFi/Bluetooth Connectivity by extension sockets |
| Power Supply |
9-28 VDC |
| Extension Sockets |
1x M.2 Key-E, 1x 5V FAN, 1x SPI, 1x I2S, 2x I2C, 2x UART |
| Mass Storage |
1x M.2 Key-M 2230 |
| Ambient Conditions |
-25°C ... +85°C |
| Form Factor / Dimensions |
60.5 mm x 91 mm, 43gr |
| Operating Systems |
Ubuntu Linux 20.04, 22.04 |
| JetPack Support |
JetPack 5.x / 6.x |
