NVIDIA® Jetson Orin™ NX & Orin Nano Railway Grade Carrier Board - RAIBOARD-ORNX
RAIBOARD-ORNX is a cutting-edge AI computing solution designed for railway applications. powered by NVIDIA Jetson Orin NX (8GB/16GB). It delivers up to 157 TOPS of AI performance. ideal for real-time data processing and machine learning tasks in railway applications.
Choose options
AI Ready For Edge Analytics With 157 TOPS Performance
The RAIBOARD-ORNX is a cutting-edge AI computing solution designed for railway applications, powered by NVIDIA Jetson Orin NX (8GB/16GB). It delivers up to 157 TOPS of AI performance with Orin NX super mode support, ideal for real-time data processing and machine learning tasks.
EN50155 Railway-Grade
The RAIBOARD-ORNX is designed to meet EN50155 railway standards, ensuring durability and reliability in harsh railway environments.
AI-Powered Performance
Equipped with NVIDIA Jetson Orin NX, it delivers up to 157 TOPS of AI performance, ideal for real-time data processing and machine learning tasks.
High-Speed Connectivity
Features dual Gigabit Ethernet, USB 3.2, WiFi, Bluetooth, LTE, and 5G support for seamless railway communication.
Robust & Secure Design
Built to withstand extreme temperatures (-25°C to 85°C), vibration, and shock, making it suitable for critical railway applications.
Enhanced Storage Capabilities
Supports dual M.2 SSD slots, providing high-speed and large-capacity storage for video analytics and monitoring applications.
Energy Efficient Operation
Designed for low power consumption (<60 Watts), ensuring energy efficiency while maintaining high performance.
NVIDIA® Jetson Orin™ NX & Orin Nano Railway Grade Carrier Board - RAIBOARD-ORNX Use Cases
RAILWAY
FORECR's railway-grade computing solutions, equipped with rugged BOX PCs integrated with NVIDIA Jetson modules, support critical railway applications such as train control, signaling, and trackside monitoring, ensuring safe and efficient operations in railway transportation networks.
AGRICULTURE
Facilitate precision agriculture applications by providing real-time data analysis for tasks such as crop monitoring, irrigation management, and yield optimization, enabling farmers to increase productivity and reduce resource usage.
MARINE
Enhance marine systems with robust onboard control, navigation, and real-time data processing capabilities, ensuring efficient and safe operations in maritime environments.
NVIDIA® Jetson Orin™ NX & Orin Nano Railway Grade Carrier Board - RAIBOARD-ORNX Technical Specifications
| Supported Modules | NVIDIA Jetson Orin Nano 4GB / 8GB NVIDIA Jetson Orin NX 8GB / 16GB |
| Memory |
4 GB 64-bit LPDDR5 / 8 GB 128 bit |
| Graphics Interfaces |
1x HDMI 2.0(max resolution 3840x2160) |
| Interfaces |
2x Gigabit Ethernet 1x USB 3.1 Type-A 1x USB 3.1 Type-C 2x CAN Bus (Isolated) 2x RS232/RS422/RS485 (Isolated) 4x Digital In, 4x Digital Out (Isolated) |
| Wireless Communication |
WiFi/Bluetooth/LTE Connectivity by extension sockets |
| Power Supply |
10-75 VDC |
| Extension Sockets |
1x M.2 Key-E, 1x M.2 Key-B, 1x SIM |
| Mass Storage |
2x M.2 Key-M SSD Slot |
| Ambient Conditions |
-25°C ... +85°C |
| Form Factor / Dimensions |
160 mm x 200 mm, 290gr |
| Operating Systems |
Ubuntu Linux 20.04, 22.04 |
| Standards (with Raibox chassis) |
EN50155, EN45545-2 HL3, EN61373, EN60068, IP67 |
| JetPack Support |
JetPack 5.x / 6.x |
